Azenco K-BANA Anchored Edition 10×10 — Manual Louvered Aluminum Pergola
The K-BANA Anchored Edition mounts directly onto a surface you already have — an existing patio, deck, or poolside slab — for a clean, built-in look that reads as part of the architecture rather than a structure set on top of it. A hand crank tilts the dual-zone aluminum louvers from wide open to fully closed, so you control sun, shade, and airflow across two sections independently.
There is no wiring, no motor, and no electronics, which is the point: nothing to power, nothing to fail, and no electrician needed. An integrated gutter system channels rainwater away through the frame to keep the space below dry, and the 6063-T6 extruded aluminum structure with AAMA 2604 powder coating is rated for winds up to 105 mph and snow loads up to 25 lbs per square foot. Because the K-BANA is modular, units can be combined side by side or back to back later if you expand the space.
Key Features
- Anchors to an existing surface — flush, built-in appearance on a patio, deck, or slab
- Dual-zone louvered roof — control sunlight and ventilation independently across two sections
- Manual crank operation — no power, no wiring, no electronics to maintain
- Integrated drainage — gutter system channels rainwater away from the seating area
- 6063-T6 extruded aluminum with AAMA 2604 standard powder coating
- Rated to 105 mph wind and 25 lbs/sq ft snow load
- Modular — combine multiple units side by side or back to back
- Optional side wall panels for privacy and enclosure when you want it
Included in the K-BANA Anchored Edition
- 4″ × 5″ platform beam
- 6063-T6 aluminum structure
- Standard powder coating, AAMA 2604
- 4″ × 4″ roof beams
- Manual aluminum louvered roof
- Handle with crank
Specifications
| Model | Azenco K-BANA, Anchored Edition |
| Size | 10 × 10 ft |
| Structure Type | Anchored to existing surface |
| Roof Type | Dual-zone louvered, manual crank adjustment |
| Frame Material | 6063-T6 extruded aluminum |
| Finish | Standard powder coating, AAMA 2604 |
| Wind Rating | Up to 105 mph |
| Snow Load | Up to 25 lbs per sq ft |
| Drainage | Integrated gutter system |
| Wall Color Options | Black, Gray |
| Power Required | None — fully manual |
| Integrated Lighting/Heating | Not included |
| Expandability | Modular — combine units side by side or back to back |
Documents
- K-BANA Assembly Manual (Combined)
- K-BANA Assembly Manual — Without Floor Truss
- K-BANA Design Sheet — Manual Louvered Pergola
Is the K-BANA Anchored Edition 10×10 right for you?
The Anchored Edition is the choice when you already have the ground surface. It mounts onto an existing patio, deck, or slab for a flush, built-in look — so you're buying the structure and roof, not a floor you don't need.
Buy the Anchored Edition 10×10 if:
- You have an existing patio, deck, or concrete slab to mount onto
- You want the pergola to look built-in rather than free-standing
- A 10 × 10 ft footprint suits your space and seating plan
Consider another model if:
- You don't have a finished surface — the Platform Edition 10×10 includes a built-in floor and can stand anywhere
- You need more covered area — see the Anchored Edition 12×12
- You want motorized louvers and a higher weather rating — the Sundance Motorized Louvered Pergola is rated to 150 mph wind and 60 lbs/sq ft snow
Not sure whether you need the floor or not? Call a specialist at (786) 761-9155 — we'll look at your surface and confirm before you order.
Frequently asked questions
What's the difference between the Anchored and Platform editions?
The Anchored Edition mounts onto a surface you already have — a patio, deck, or slab — for a flush, built-in look. The Platform Edition includes its own built-in floor, so it's a complete standalone structure that can be placed on ground that isn't already finished. Choose Anchored if your surface is ready; choose Platform if it isn't.
Do the louvers need electricity?
No. The K-BANA uses a hand crank to tilt the louvers, with no motor, wiring, or electronics. That means no electrical work at installation and nothing electronic to service later.
What weather can it handle?
The structure is rated for winds up to 105 mph and snow loads up to 25 lbs per square foot. With the louvers closed, the integrated gutter system channels rainwater away to keep the area below dry.
Can I combine multiple units?
Yes — the K-BANA is modular, so units can be combined side by side or back to back to cover a larger area or create a custom layout. Call us before ordering if you're planning a multi-unit configuration so we can spec it correctly.
Does it include lighting, heating, or privacy walls?
Built-in lighting and heaters are not included. Side wall panels are available as an option and add enclosure and privacy without making the space permanently closed in. Wall colors are offered in black and gray.
Do I need professional installation?
The K-BANA is designed for straightforward assembly and the full manuals are available above, but because the Anchored Edition fixes to an existing surface, anchoring should suit your substrate and local code. Professional installation is recommended for the best result and long-term durability.
How is it delivered?
Free and fully insured by freight carrier, with tracking and a scheduled delivery appointment. Plan a clear access route and a level placement area before delivery day. Our 24/7 US-based support can help you prepare.
