The Aeromist Auto Drain Valve automatically drains water from the mist line after every use — preventing dripping nozzles and calcium buildup, and extending nozzle life. Available for high-pressure or low-pressure systems.
After the pump shuts off, this valve opens automatically to drain residual water from the mist line, eliminating the drip that causes calcium deposits on nozzles and surrounding surfaces.
⚠ Select the correct variant for your system:
• High Pressure (SKU 52000) — requires 250 PSI to close. Not suitable for low-pressure systems.
• Low Pressure (SKU 52000-LP) — requires 35 PSI to close. Not suitable for high-pressure systems.
| Specification |
High Pressure (SKU 52000) |
Low Pressure (SKU 52000-LP) |
| Closing Pressure |
250 PSI |
35 PSI |
| Thread |
10/24 Standard |
|
| Weight |
0.02 lbs |
0.03 lbs |
| Dimensions |
1" × 0.5" × 0.5" |
1.25" × 0.5" × 0.5" |
| Compatible With |
High-pressure misting systems |
Low-pressure misting systems only |
| Not Compatible With |
Low-pressure systems |
High-pressure systems |
| Function |
Drains mist line after use — prevents dripping and calcium buildup, extends nozzle life |
