The Dual Fan Mist360 Cyclone System delivers maximum outdoor cooling at exceptional value — two Cyclone fans and 16 ruby nozzles on a single 1,000 PSI pump for large patios and covered spaces.
With a total of 16 ruby-orifice nozzles emitting 1,000 PSI flash-evaporated mist combined with 27+ mph airflow from the patent-pending curved chutes of two Cyclone fans, this kit provides maximum cooling coverage for outdoor spaces over 250 sq. ft. Great value for larger residential patios or light commercial use. Patented. Designed and built in the USA.
| Specification | Detail |
|---|---|
| Area Cooled | More than 250 sq. ft. |
| Number of Fans | 2 |
| Fan Size (each) | 18" Diameter × 8" tall |
| Weight (each) | 7 lbs |
| Nozzles Total | 16 ruby-orifice (8 per fan), sized for your geographic location |
| Airflow | 27+ mph per fan through curved chutes |
| Pump | 1,000 PSI high-pressure pump assembly (shared) |
| Feed Line (included) | 100 ft high-pressure nylon flex (SS upgrade available) |
| Hang Height | Between 7 and 8 feet |
| Mounting | Standard ceiling fan bracket to J-Box |
| Fan Motor (each) | 100–240VAC, 50/60Hz, 0.55A, 63W |
| Patented | Yes |
| Made In | USA |
What's Included
- 2 Mist360 Cyclone fans
- 1 high-pressure pump assembly
- Low-pressure water hose with in-line water filter (sediment filter with calcium inhibitor)
- 100 feet of high-pressure feed line (nylon flex, or upgrade to stainless steel) with attachment clips
- 16 ruby-orifice misting nozzles (2 sets of 8, sized for your geographic location)
- 2 3/16" brass compression union
- 1 3/16" brass compression "T"
- 1 1/4" to 3/16" compression fitting adapter
- 2 aluminum down rods, sized 4" and 24"
- 2 ceiling mounting kits
- 1 installation manual
