The most immersive DIY golf simulator on the market. The Carl's Place Curved Golf Simulator Enclosure Kit with Premium Golf Impact (10'H × 15'W × 8'D) is the first-ever DIY curved golf simulator kit, featuring an innovative curved impact screen that creates a panoramic, wide-field-of-view experience you can't get from any flat enclosure.
Designed for high-end residential and commercial use, this kit delivers a lifelike simulation environment — with premium materials, a single-projector setup, and optional custom sizing down to the inch.
What's Included
- Premium Golf Impact — Three-layer heavy-duty polyester screen delivering vivid, true-to-life projector images with superior impact resistance and a seamless floor-to-turf view.
- BlackStop™ Enclosure Surround Fabric — premium knit fabric blocks ambient light and enhances immersion
- Foam Insert Kit — pre-cut foam inserts to protect the frame and reduce rebound
- Steel 2" Fittings — for 2" EMT framing pipes (sold separately)
- Ball Bungees and Zip Ties — to tension and mount the curved screen
Pipe Framing Kit is NOT included. Add the Pipe Framing Kit or source 2" EMT locally (true OD: 2.197" / 55.8mm).
Enclosure Specifications — 10'H × 15'W × 8'D
| Specification | Detail |
|---|---|
| Enclosure Size (H × W × D) | 10'H × 15'W × 8'D |
| Depth Note | 8' depth — standard starting depth for the Curved Kit, with 9.5" backset fitting behind screen. |
| Rear Backset Fitting | Adds 9.5" to total depth — minimum 9.5" rear clearance required |
| Ceiling Clearance Recommended | 6–7 inches above enclosure height |
| Side Clearance Recommended | 2–3 inches each side |
| Minimum Recommended Room Width | 15'8" |
| Minimum Recommended Room Height | 10'8" |
| Frame Pipe Required | 2" EMT (true OD 2.197" / 55.8mm) — NOT 1" EMT or PVC |
| Projector Setup | Single projector — optional image warping software recommended for full curved correction |
Key Features
- First-ever DIY curved golf simulator kit — panoramic curved screen creates an unmatched wide field of view
- Curved Impact Screen — enhances simulation depth and peripheral immersion vs. flat screens
- Single Projector Setup — one projector is enough; optional image warping software for full correction
- BlackStop™ Enclosure Fabric — blocks ambient light, deepens contrast
- Foam Insert Kit Included — protects frame, reduces rebound and noise
- DIY-Friendly Assembly — step-by-step instructions included
- Custom Sizing Available — standard sizes or fully custom to the inch
- Recommended hitting distance: 10–12 feet from screen
